| Working height max: | 13,1m |
|---|---|
| Platform height max: | 11,1m |
| Range max: | 6,1m |
| Lifting capacity max: | 220kg |
| Maximum number of people in the lift: | 2 |
| Basket size (LxWxH): | 1,2 x 0,8 x 1,1m |
| Boom rotation: | 355° |
| Jib length: | 1,2m |
| Power outlet in basket: | Yes |
| Wheel drive: | Yes |
| Support legs: | Hydraulic |
| Support leg width: | 3,45m |
| Slope: | 8% |
| Transport length: | 6,35m |
| Transport width: | 1,55m |
| Transport height: | 1,99m |
| Net weight: | 1450kg |
| Weight | 1450 kg |
| Dimensions | 635 × 155 × 199 cm |
Europelift TM13 G – 13m
Europelift TM13 G is a practical, user-friendly and robust trailer-mounted lift that makes difficult jobs easy. The combination of articulated arm and jib provides easy access to the most difficult areas with up to 220kg in the basket.
Europelift TM13G has a working height of up to 13.1 meters, and can be loaded with as much as 220 kg. The lift is standard specified with petrol engine, operation on wheels, hydraulic support legs, rotatable basket and user-friendly proportional control system.
Call for Price
Send RequestStandard equipment:
• 230V and Honda motor
• Telescopic boom lift with proportional control
• 1,3m jib
• 230V AC outlet in the basket
• Wheel drive
• Platform level leveling with auto-correction of 3 °
• Chassis leveling sensor of 1 °
• Aluminum Basket with wide toolbox, safety handrail and harness points
• Proportional electro-hydraulic controls with fingertip joystick
• Ground pressure sensors on all anchor plates with audible and visible alarms
• Hour meter
• CE marking and EU approved for road
• Ground and upper controls with tarpaulin cover
• Manual recovery with hand pump
• Automatic reverse and overrun brakes plus parking brake
• Color of machine: RAL3002 (red)
Additional equipment:
• Operating option 230V
• Option Battery operation
• Automatic chassis level
• Custom color
• Dual-Power source 230V & Honda
• Battery power 24V 225Ah
• On-board 230V Generator 5KV Honda EM5500
• G.R.P. basket with toolbox (2 people)
• Anchor plate mats
